Denon AVR-5803 Service Manual

92
AVR-5803/AVC-A1SR
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
1 1U-3425 Digital unit Ass'y for EU,EC 1
1 1U-3425A Digital unit Ass'y for E2,E1,E1C,EUT 1
2 1U-3426 DSP unit Ass'y 1
3 1U-3292G Front unit Ass'y for EU,EC 1
3 1U-3292H Front unit Ass'y for E2,E1,E1C 1
3 1U-3292M Front unit Ass'y for EUT 1
3-1 FLD unit
3-2 Remocon unit
3-3 Tact switch unit
3-4 Master volume unit
3-5 H/P unit
3-6 Power switch unit for E2,E1,E1C,EUT
3-8 Non lock switch unit for EU,EC
3-9 AC outlet unit for EU,EC,EUT
3-11 Multi out unit
4 1U-3460 Reg. & SP unit Ass'y for EU,EC 1
(1U-3294G)
4 1U-3460A Reg. & SP unit Ass'y for E2,E1,E1C,EUT 1
4-1 SP unit-1
4-2 SP unit-2
4-4 Rectifier unit
4-5 Reg. drive unit
4-7 Diode unit
5 1U-3404 Pre reg. unit Ass'y for EU,EC 1
5 1U-3404A Pre reg. unit Ass'y for E2,E1 1
5 1U-3404F Pre reg. unit Ass'y for E1C 1
5 1U-3404E Pre reg. unit Ass'y for EUT 1
5-1 Primary unit
5-2 FLAC unit
5-3 Reg. conn. unit
5-4 M5V unit
5-5 Pre reg. unit
5-6 Pre fuse unit
5-7 IC509 unit
5-8 D508 unit
5-9 D509 unit
5-10 D510 unit
5-11 D511 unit
5-12 D512 unit
5-13 D513 unit
5-14 D514 unit
5-15 D515 unit
5-16 D516 unit
5-21 IC501 unit
5-22 IC502 unit
5-24 IC201 unit
6 1U-3296G Power amp. unit Ass'y for EU,EC 1
6 1U-3296H Power amp. unit Ass'y for E2,E1,E1C,EUT 1
6-1 Power amp. L unit
6-2 Power amp. R unit
6-3 TR113 unit
6-4 TR213 unit
6-5 TR313 unit
6-7 TR114 unit
Note: The symbol in the column "Remarks" indicate the following destinations.
EU: U.S.A. model (AVR-5803) E1: Asia model
EC: Canada model (AVR-5803) E1C: China model
E2: Europe model EUT: Taiwan R.O.C. model
6-8 TR214 unit
6-9 TR314 unit
6-10 TR414 unit
7 1U-3298G Tuner unit Ass'y for EU,EC 1
8 1U-3436 Ext. in vol. unit Ass'y for EU,EC 1
8 1U-3436A Ext. in vol. unit Ass'y for E2,E1,E1C,EUT 1
9 1U-3437 Audio & video in unit Ass'y for EU,EC 1
9 1U-3437A Audio & video in unit Ass'y for E2,E1,E1C,EUT 1
9-1 V. conn. -1 unit
9-2 V. conn. -2 unit
9-3 V. conn. -3 unit
9-4 C. video unit
9-5 232C unit
9-7 Comp. RGB unit
9-8 Audio in unit
9-9 Amp. conn. L unit
9-10 Amp. conn. R unit
10 1U-3444 Video convert unit Ass'y for EU,EC 1
10 1U-3444A Video convert unit Ass'y for E2,E1,E1C,EUT 1
10-1 Convert unit Ass'y
10-2 Y/C sep. unit
10-3 S. video unit
11 411 1939 105 Front chassis for EU,EC 1
11 411 1939 118 Front chassis for E2,E1,E1C,EUT 1
12 412 4473 108 Headphone bracket 1
13 203 6385 056 4P KR-KR ribbon 150 CY041 1
14 441 1793 009 Snap plate 1
15 204 2543 057 7P KR-KR ribbon 150 CN072 1
16 411 1938 203 Side chassis for EU,EC 2
16 411 1938 216 Side chassis for E2,E1,E1C,EUT 2
17 105 1344 222 Back plate for EU,EC 1
17 105 1344 235 Back plate for E2,E1,E1C,EUT 1
18 105 1342 279 Back panel (EU) for EU,EC 1
18 105 1342 295 Back panel (E2/E1) for E2,E1 1
18 105 1406 005 Back panel (E1C) for E1C 1
18 105 1406 018 Back panel (EUT) for EUT 1
19 205 1116 006 Terminal Ass'y 1
20 233 6408 002 Sub trans (583E3) for EU,EC,EUT 1
20 233 6411 002 Sub trans (A1SRE1E2) for E2,E1 1
20 233 6414 009 Sub trans (A1SRE1C) for E1C 1
21 203 3970 008 AC inlet 1
22 203 2417 009 2P VA-VA connector cord CN025, for EU,EC,EUT 1
23 445 8004 007 Wire clamper 24
24 414 0900 202 Shield cover (A) for EU,EC 1
24 414 0900 215 Shield cover (A) for E2,E1,E1C,EUT 1
25 414 0901 201 Shield plate (AV) 1
26 412 2741 007 P.W.B. holder (H=8) 4
27 412 2741 036 P.W.B. holder (H=10) 3
28 412 4127 001 P.W.B. bracket (B) for EU,EC 1
28 412 4127 014 P.W.B. bracket (B) for E2,E1,E1C,EUT 1
29 412 2814 002 Card spacer (L=8) 2
30 449 0133 017 P.W.B. holder for EU,EC 1
31 449 0114 010 Edging (CE-016) 3
