Buttons
When the key control mode is on, press these buttons to
l
ower the key.
Buttons
When the key control mode is on, press these buttons to
raise the kev.
BRAKE Button
When the CD "1 " or "2" button is pressed while press-
i
ng this button, CD 1 or 2 is set to the brake mode and
brake playback is enabled. (The
CD "1
11
Press the
or "2" button again wnne pressing the
button to return to the normal playback mode. (The
i
ndicator turns off.)
PITCH BEND- and PITCH BEND+ Buttons
The pitch changes temporarily while these buttons are
pressed. Release the buttons to return to the original
BPM.
REVERSE Buttons
Press these buttons to turn the sampler's reverse play-
back mode on and off.
After pressing the REVERSE button, the direction of play-
back does not change until the PLAY/PAUSE button is
pressed.
The REVERSE LED lights when the reverse playback
mode is on.
DN-2500F (Main Unit) Rear Panel
LINE OUT 1 and 2
The audio signals from each player are output from these
j
acks.
REMOTE
Connect this connector to the RC-44 control unit using
the included control cord.
FADER IN
Use this when using the unit with a console fader. (Mini
Jack)
1 and 2 Buttons
Use these buttons to selectwhich playerthe number but-
tons will function for.
MAIN POWER (Europe and Asia Model only)
Vlake sure to switch on.
MEMO CALL Button
When the CD "1 " or "2" button is pressed while press-
i
ng this button, the data stored in the memory is called
out and set.
PRESET Button
Press the CD "1 " or "2" button while pressing this but-
ton to set CD 1 or 2 to the preset mode.
Press this button to set the preset data.
Press the button again while pressing the CD "1 " or "2"
button to turn the preset mode off.
CLEAR Button
Press this button to clear the data which was input using
the number buttons.
0 ---9 Buttons (Number Buttons)
Use these buttons to input track numbers, times (min-
utes and seconds), and select the PRESET items.
VOICE REDUCER Button
When the CD "1 " or "2" button is pressed while press-
i
ng this button, CD 1 or 2 is set to the voice reducer mode,
and the level of the vocals in the music is reduced. (The
i
ndicator lights.)
Press the CD "1 " or "2" button again while pressing the
button to return to the normal playback mode. (The
i
ndicator turns off.)
MEMO Button (Custom Setting Memory)
Press the CD "1 " or "2" button while pressing this but-
ton to store the CD 1 or 2 settings (disc data, cue point,
l
oop start point, loop end point, pitch). (The
for lights.)
RC-44 (Control Unit) Rear Panel
Control Connector
Connect this connector to the REMOTE connector on the
DN-2500F (main unit) using the included control cord.
TRACK, MINUTE, SECOND and FRAME
Displays
These displays indicate information on the current posi-
tron and time.
BAR Indicator
These ten indicators provide a visual display of the
approximate position of the pickup within the current
track.
ELAPSED Indicators
These indicate that the time shown on the display is the
elapsed time.
REMAIN Indicators
These indicate that the time shown on the display is the
remaining time.
SINGLE Indicators
When these indicators are lit, playback will stop at the
end of the track.
CONTINUE Indicators
When these indicators are lit, playback will continue until
the end of the disc.
i
ndica-
1 1
i
ndicator lights.)
