PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
EA : Australia model E1C : China model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
7 nsp TOUCH BOARD - 1 *
9 nsp AMP BOARD - 1 *
16 8U6391006300D MIAN BOARD - 1 *
1 nsp SPONGE FOR TOUCH FPC FIX 5050000755S7 1 *
2 nsp MYLAR TOUCH MARK 413100028997 1 *
3 nsp TOUCHPAD FPC 3231C00142F7 1 *
4 nsp TOUCH PCB BRACKET 4011700038V7 1 *
5 nsp SPONGE FOR TOUCH BOARD 5050000663S7 1 *
11 nsp POWER CABLE RUBBER 4240000335D7 1 *
12 nsp AMP CABLE RUBBER 4240000334D7 1 *
14 nsp REAR CABINET ASS'Y 4011100072V7 1 *
15 nsp METAL BRACKER 4021700030M7 2 *
18 nsp LOCK METAL 402300001727 1 *
19 nsp BOTTOM COVER ASS'Y 4011100073V7 1 *
20 nsp BOTTOM SPONGE 50*3*0.5mm 5050000747S7 2 *
21 nsp FOOT RUBBER D14mm 4240000317D7 2 *
23 nsp FOOT RUBBER L164mm 4240000316D7 1 *
26 924323100150D SPEAKER 3320000075V7 2 *
27 8M3090000100D DRAWER - 1 *
28 nsp SPONGE FOR DRAWER TO FRONT 5050000669S7 1 *
29 nsp SPONGE FOR FRONT TO REAL 5050000664S7 2 *
30 nsp SPEAKER FRAME ASS'Y 4011100080V7 1 *
32 nsp BATTERY SPONGE 5050000712S7 2 *
z
33 924692100020D BATTERY-14.4V 2200mAh 3030000056Y7 1 *
34 nsp SPONGE FOR BATTERY COVER 5050000668S7 2 *
35 nsp BATTERY COVER 4011000103V7 1 *
37 nsp WOVEN SHEET 880*8mm 4130000020W7 1 *
38 924437100190D SPEAKER FRAME ASS'Y 4011100080V7 1 *
39 nsp IO PANEL 401590000197 1 *
SCREWS
6 nsp P3*8 FOR TOUCH BOARD 6101000094R7 2 *
8 nsp SELFTAPPING P3*12mm 6101000158R7 2 *
10 nsp SELFTAPPING P3*12mm 6101000158R7 2 *
13 nsp MACHINE SCREW M3.0*L5.0mm 6100000113R7 2 *
17 nsp SELFTAPPING P3*12mm 6101000158R7 1 *
22 nsp SELFTAPPING P3*12mm 6101000158R7 6 *
24 nsp SELF-TAPPING P4.0*11mm 6101000180R7 8 *
25 nsp SELF-TAPPING P3.5*11.5mm 6101000169R7 4 *
31 nsp SELF-TAPPING P3.5*16mm 6101000174R7 6 *
36 nsp SCREW SELF-TAPPING F3.0*8mm 6101000170R7 4 *
NOTE:
To replace the MAIN PCB ASSY. please set resistors according to 38 page of "Destination Setting"
