28
–
EN
DVD SETUP
Display Setting
You can change certain aspects of the DVD display screens,
still mode setting, Progressive and HDMI settings.
Press the SETUP button in stop mode.
Press the Cursor buttons (s or B) to select CUS-
TOM, then press the ENTER button.
•
The CUSTOM mode will appear.
Press the Cursor buttons (s or
B) to select DISPLAY, then press
the ENTER button to confirm.
Press the Cursor buttons (K or
L) to select an item, then press
the ENTER button.
TV ASPECT
(Default: 4:3 LETTER BOX)
• Press the Cursor buttons (K or
L) to select a setting, then press
the ENTER button.
• Select 4:3 LETTER BOX.Black
bars may appear at the top and bot-
tom of the screen, depending on
the proportion of the TV screen.
• Select 4:3 PAN & SCAN for a full height picture with both
sides adjusted.
•
Select 16:9 WIDE if a wide-screen TV is connected to the DVD player.
• Select 4:3 SQUEEZE when the TV screen is too large hor-
izontally at 16:9 WIDE setting and when it is impossible to
adjust the screen size using the TV’s controls.
STILL MODE
(Default: AUTO)
• Press the Cursor buttons (K or
L) to select a setting (AUTO,
FIELD, or FRAME), then press
the ENTER button.
• This function allows you to
adjust picture resolution and
quality in still mode.
QUICK
4
3
2
1
DISPLAY
AUTO
FIELD
FRAME
STILL MODE
In setup menu, QUICK mode, CUSTOM mode and INITIALIZE mode are available (refer to pages 28-32).
QUICK mode consists of items of which the setting menus are frequently used, and they are accompanied
with mark. You can make all settings in CUSTOM mode.
QUICK
Language options may not be available on some discs.
Press the SETUP button in stop mode.
Press the Cursor buttons (s or B) to select
CUSTOM, then press the ENTER button.
• The CUSTOM mode will appear.
Press the Cursor buttons (s or B) to select LAN-
GUAGE, then press the
ENTER button to confirm.
Press the Cursor buttons (K or
L) to select an item, then press
the ENTER button.
DIALOG
(Default: ORIGINAL)
• Sets the audio language.
SUBTITLE
(Default: OFF)
• Sets the subtitle language.
DISC MENU
(Default: ENGLISH)
• Sets the language for DVD Menu.
OSD
(Default: ENGLISH)
• Sets the language for the on-screen display.
Press the Cursor buttons (K or L) to select a lan-
guage, then press the ENTER button.
•
If OTHER is selected for DIALOG, SUBTITLE or DISC
MENU, press four-digit number to enter the code for your de-
sired language (refer to the language code list on page 32).
•
Only the languages supported by the disc can be selected.
Press the SETUP button to exit.
NOTE:
• Language setting for DIALOG and SUBTITLE may not
be available on some discs. Then use the AUDIO and
SUBTITLE buttons. Details are on pages 25 and 26.
6
5
QUICK
4
3
2
1
Language Setting
DISPLAY
TV ASPECT
4:3 LETTER BOX
STILL MODE AUTO
VIDEO OUT SCART
PROG.MODE AUTO1
HDMI SELECT YCbCr
HDMI PICTURE NORMAL
DISPLAY
TV ASPECT
4:3 LETTER BOX
4:3 PAN & SCAN
16
:9 WIDE
4:3 SQUEEZE
LANGUAGE
DIALOG ORIGINAL
SUBTITLE OFF
DISC MENU ENGLISH
OSD ENGLISH
• An individual picture on TV screen is called as “frame”,
which consists of two separate images called as “field”.
Some pictures may be blurred at the AUTO setting in
still mode due to their data characteristics.
• AUTO: Automatically selects the best resolution setting
(FRAME or FIELD) based on the data characteristics of
the pictures.
• FIELD: Select FIELD when the pictures are still unsta-
ble even if AUTO is selected. FIELD stabilizes the pic-
tures, although the picture quality may become coarse
due to the limited amount of data.
• FRAME: Select FRAME to display relatively motionless
pictures in higher resolution. FRAME improves the pic-
ture quality, although it may unstabilize the pictures due
to simultaneous output of two field data.
VIDEO OUT (
Default:
SCART)
•
Press the Cursor buttons (K or
L) to select a setting (SCART,
COMPONENT INTERLACE or
COMPONENT PROGRESSIVE),
then press the ENTER button.
• This setting will be effective
when you exit the setup screen by pressing the SETUP
button.
• When VIDEO OUT is COMPONENT PROGRESSIVE,
P.SCAN appears on the DVD player’s front panel dis-
play after you exited the setup screen.
• Refer to page 12 for more details.
• In the HDMI output mode, even when VIDEO OUT is
set to COMPONENT PROGRESSIVE, signals are out-
put always as Interlace.
PROG.MODE (Default: AUTO1)
• Press the Cursor buttons (K or
L) to select a mode for the pro-
gressive scan output, then press
the ENTER button.
• AUTO1:
mode suitable for images
on the film material.
• AUTO2: mode for images on the material of 30-frame
film.
• VIDEO1: mode for normal video material.
• VIDEO2:
mode for video material with less movements
.
• VIDEO3:
mode for video material with many movements.
HDMI SELECT (Default: YCbCr)
• Select an HDMI output mode
between YCbCr and RGB.
• When the connected equipment
is not compatible with YCbCr,
HDMI signal is output as RGB
regardless of the setting.
HDMI PICTURE (Default: NORMAL)
• Select a HDMI picture mode
between NORMAL and
ENHANCED.
• Select ENHANCED if the black-
white contrast is not clear.
• This setting is effective only for
HDMI RGB output.
Press the SETUP button to exit and activate the new
settings.
NOTES:
• Be sure to press the SETUP button, or the setting will
not work.
•
When changing the VIDEO OUT setting (SCART, COM-
PONENT INTERLACE or COMPONENT PROGRES-
SIVE), connect to a Video jack or an S-Video jack on the
TV. If the setting is changed, for example, to SCART
while the Component Video jacks are used to connect to
the TV, a distorted video signal may be output.
5
DISPLAY
SCART
COMPONENT INTERLACE
COMPONENT PROGRESSIVE
VIDEO OUT
DISPLAY
PROG.MODE
AUTO1
AUTO2
VIDEO1
VIDEO2
VIDEO3
DISPLAY
TV ASPECT
4:3 LETTER BOX
STILL MODE AUTO
VIDEO OUT SCART
PROG.MODE AUTO1
HDMI SELECT YCbCr
HDMI PICTURE NORMAL
DISPLAY
TV ASPECT
4:3 LETTER BOX
STILL MODE AUTO
VIDEO OUT SCART
PROG.MODE AUTO1
HDMI SELECT YCbCr
HDMI PICTURE NORMAL
E61E2/E3ED_EN.qx3 05.7.7 17:03 Page 28
