21
5. SMPSPCBASSY
(1) Remove the screws.
(2) Remove the screws.
Proceeding : SIDE PANEL
TOP COVER
CD MECHA ASSY
FRONT PANEL ASSY
SMPC PCB ASSY
View from the bottom
CN221 CN222
Shooting direction: C

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon RCD-N8 and is the answer not in the manual?

Denon RCD-N8 Specifications

General IconGeneral
Remotely operatedYes
Security algorithmsWPS
Supported radio bandsFM, VHF
Built-in storage mediaNo
Audio formats supportedMP3
Internet radio services supportediDevice, iTunes
Network streaming services supported-
Product colorWhite
RMS rated power130 W
Wi-Fi standards802.11b, 802.11g
Digital audio optical out1
Apple docking compatibilityiPhone, iPod
AC input voltage230 V
AC input frequency50 Hz
Power consumption (typical)50 W
Weight and Dimensions IconWeight and Dimensions
Depth299 mm
Width280 mm
Height112 mm
Weight4000 g
