Digi One IAP User Manual

Hardware information
This topic provides hardware specifications, regulatory and safety statements, and certifications for
the Digi One IAP.
Hardware specifications
Category Specification Value
Power requirements
2-pin Terminal Connector
(green)
+9 to +30 VDC 500 mA (max)
external power supply
RJ-45 Powered Ethernet +37 to +57 VDC 100 mA (max)
(802.3afcompliant)
Environmental
Ambient temperature 0 to 60 degrees C
Relative humidity not to exceed
95% noncondensing over the
temperature range of from 4C to
45C. Above 45C, constant absolute
humidity shall be maintained.
Relative humidity 5 to 90% non-condensing
Mechanical Width 101 mm
Height 22.5 mm
Depth 120 mm
CAUTION! This unit has two power inputs. For total isolation from electrical shock and
energy hazard, disconnect both power inputs.
Digi One IAP Family User Guide
25

Digi One IAP Specifications

General

Brand	Digi
Model	One IAP
Category	Server
Language	English
