The information contained here are property of DIGITAX Automotive Electronics Italy, and extremely confi dential. Any disclosure, copying, distribution to third
party
is strictly prohibited.
10
Electrical Connec on Table
MECHANICAL TRANSDUCER
or
CAR ODOMETER INPUT
PRINTER
GREY
VIOLET
GREEN
YELLOW
Passenger Sensor
PINK
RED
RED
BLACK
fuse 2 A
fuse 2 A
fuse 2 A
fuse 2 A
fuse 2 A
fuse 2 A
CAR LIGHT SWITCH
+12 V
BROWN
WHITE
fuse 2 A
* For Detailed pin-out connecon go to the “Connector and Cable” Chapter (page 15)
GREEN
YELLOW
Detailed pin-out on
“Windows RS232 / USB”
Chapter - page 54
