Manual fault analysis
Technical Data
32
27.0
Failure : No cooling (the cooling unit at the back of the appliance is cold)
Possible Cause Fault Elimination (authorised service provider)
a.) Defective heating shell ?
b.) Defective Air and / or
Evaporator-Sensor?
c.) Defective electronic ?
d.) The appliance is in defrost
mode.
a.) Measure resistance, replace heating shell if
required.
230V / 65 W ~ 800W
230V / 80 W ~ 650W
b.) Pull sensor off electrics (air-sensor X9,
evaporator-sensor X8) and check by means of
measurement.
Ambient Temperature (°C) Resistance (kOhm)
0° 27,70
10° 18,07
15° 14,74
20° 12,11
25° 10,00
c.) Plug in and measure voltage at
heating shell output (X3)!
After max. 5 seconds, the heating
shell will be driven by mains voltage (230V) for
20 seconds.
d.) Pull out plug and put back in again.
28.0
Model HiPro 3000
Model HiPro 4000 with cooling unit cover + feet
Casing Plastic
Gross Volume ( litres) 28
cooled / uncooled 28 / -
Dimensions (mm)
(H x W xD) 527 x 388 x 418
Electrical Rating (W) 65
Power Consumption
kWh / 24h* 0,6
Net Weight (kg) 12
Assembly x
freestanding x
Casing Plastic
Gross Volume ( litres) 37
cooled / uncooled 37 / -
Dimensions (mm)
(H x W xD) 559 x 405 x 452 601 x 405 x 472
Electrical Rating (W) 65
Power Consumption
kWh / 24h* 0,7
Net Weight (kg) 13.5 14.5
Assembly x
freestanding xx
