Dometic RH330LD User Manual

Securing
RH 356LD/E, RH 456LD/E
RH136, RH137, RH330, EA330, RH340, RH341, RH360,
RH361, RH437, RH447, RH430, RH440, RH41, RH460,
RH461, EAW 3220
The miniBar must be screwed onto the cupboard using the lower hinges.
9
Recess dimensions in mm:
Model Hight Width Depth
RH 430LD, RH 330LD 526 388 432
RH 436D, RH 136D 526 388 432
EA 330L 526 388 432
RH 440LD, RH 340LD 558 405 466
RH 447D, RH 137D 558 405 466
RH 441LD, RH 341LD 558 405 469
RH 456LD/E, RH 356LD/E 662 454 523
RH 460LD, RH 360LD 567 490 494
RH 461LD, RH 361LD 567 490 494
EAW 3220 567 490 494
1. Tighten screw.
2. Put on cap.
8.0
1. Tighten screw.
2. Put on cap.
on level with furniture

Dometic RH330LD Specifications

General

Brand	Dometic
Model	RH330LD
Category	Refrigerator
Language	English
