Technical data |
Installation instructions | Dräger Interlock
®
5x00/7x00 31
6 Technical data
7 Order list
Measuring principle Electrochemical DrägerSensor
Measuring range up to 3.0 mg/L
Ambient conditions
for operation and storage -40 to 85 °C
20 to 98 % rel. hum.
600 to 1100 hPa
No influence of changes in altitude on the
measurement result
Sensitivity drift typically 1 % of measured value/month
Display Display
Calibration interval typically 12 months
Dimensions (H x W x D)
Handset approx. 138 mm x 61 mm x 36 mm
Control unit approx. 148 mm x 90 mm x 32 mm
Weight
Interlock 5x00 handset approx. 180 g
Interlock 7x00 handset approx. 240 g
Control unit Interlock 5x00 approx. 195 g
Control unit Interlock 7x00 approx. 240 g
Voltage supply 12 to 24 V
Power consumption
maximum <2.5 A
stand-by <1 mA
Switch relay for the lead for the starter relay
continuous <16 A
peak <40 A
Output relay
switchable de-energized 48 V
switchable energized 24 V
Ignition lead 5 V to 48 V
Waiting time to be ready for measurement
Interlock 5x00 Interlock 7x00
20 °C 7 s 2 s
0°C 25 s <5 s
-25°C <60 s <60 s
-40°C <115 s <110 s
Name and description Order no.
Mouthpieces (5 pcs.), individually packaged 83 26 550
Mouthpieces (50 pcs.), individually packaged 83 27 627
Mouthpieces (300 pcs.), individually packaged 83 22 597
LTE module 83 27 080
Cable set, LIN/CAN 37 05 279
Cable set for connecting headlights 37 01 238
Cable set for connecting horn 37 01 237
Cable set for connecting external equipment
(AUX/OUT)
37 01 239
