4-4
Chapter 4 TROUBLESHOOTING GUIDE
●
Fan paper well before stacking.
●
Decrease the stacking amount of paper
.
2-3.
When P
aper Has Coiled A
round the Rubber Roll
T
urn off the machine before following the procedures below
.
T
op cover
1
Open the top cover
.
67
69
