45OPERATION AND INSTALLATION INSTRUCTIONS MN280075EN July 2018
Form 6 microprocessor-based rack-mount recloser control
CAUTION
Hazardous voltage. Open CT secondaries can generate
high voltages. Contact with CT pins of the disconnected
cable can cause electric shock and may result in personal
injury. Open recloser contacts and open disconnect
switches before disconnecting control cable. T204.3
10. Reconnect CT circuit by unshorting secondaries from
the CT shorting-type terminal block.
11. The recloser and control are ready for service. Once
installed, remove bypass switches on the recloser.
12. Disable GND TRIP BLOCKED.
A. Press the CHANGE button on the Operator Panel
to enter the CHANGE mode.
B. Depress the GND TRIP BLOCKED button within
ten seconds after entering the CHANGE mode.
ote:N If the GND TRIP BLOCK button is not depressed
within ten seconds, the function is not activated.
Additional information
CAUTION
This equipment requires routine inspection and
maintenance to ensure proper operation. If it is not
maintained, it can fail to operate properly. Improper
operation can cause equipment damage and possible
personal injury. G105.1
Replacement kits
Replacement kits for the Form 6 recloser control are
available through the factory Service Department. To
order these kits, refer to the Replacement Parts price
list for catalog numbers and pricing. Contact your
Eaton representative for additional information and
orderprocedures.
Factory-authorized service centers
Factory-authorized service centers are located throughout
the continental United States to provide maintenance,
repair and testing services for Cooper Power series
controls and reclosers. For further information, contact your
Eatonrepresentative.
Factory testing and troubleshooting classes
The factory service department offers a basic testing and
troubleshooting course for the Form 6 Microprocessor-
Based Electronic Recloser Control. This course, taught by
experienced service technicians, is held at the factory’s
in-house training facility. For additional information, contact
your Eaton representative.
Type MET recloser control tester
A 30-minute video program KSPV7 Type MET Electronic
Recloser Control Tester Operation and Testing
Procedures is available as a supplemental training aid for
servicepersonnel.
