Function menu
Refer to Table9 for the nested menu structure: Main Menu,
Sub-Menus, and Parameter
Table9. Function menu
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Sub-Menu
Level 4
Sub-Menu Parameter
Function
Code
*SETTINGS *Forward Direction Forward Set Voltage 001
Forward Bandwidth 002
Forward Time Delay 003
Fwd Line Drop Comp. Resistance 004
Fwd Line Drop Comp. Reactance 005
*Reverse Direction Reverse Set Voltage 051
Reverse Bandwidth 052
Reverse Time Delay 053
Rev Line Drop Comp. Resistance 054
Rev Line Drop Comp. Reactance 055
*Configuration Control Identification 040
Regulator Type 140
Tap Changer Type 049
Regulator Configuration 041
Control Operating Mode 042
System Line Voltage 043
Overall P.T. Ratio 044
Internal P.T. Ratio 044
C.T. Primary Rating 045
Rated Load Current 045
Adaptive ADD-AMP 5% Limit 045
Adaptive ADD-AMP 6 1/4% Limit 045
Adaptive ADD-AMP 7 1/2% Limit 045
Adaptive ADD-AMP 8 3/4% Limit 045
Demand Time Interval 046
P.I. ADD-AMP High Limit 144
P.I. ADD-AMP Low Limit 145
Vin P.T. Configuration 146
TPI Sense Method 147
Neutral Sync Retry Count 147
Motor Power Source Selection 147
Nominal Sec Load Voltage 148
Regulator Identification 141
Serial Number 142
31
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
