Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
088 Factory Access
Mode
Disabled
--- View Modify NA Disabled NA NA
•This function is used to diagnose the control when an extended communications module is in
use.
•Available options include: Disabled; Enabled.
088 Extended Comms
Status
0x0
(RUNNING OK)
--- View NA NA NA NA NA
• Provides the status of an extended communications card.
• (NOT AVAILABLE) indication is displayed if the extended communications card is not
present.
• (RUNNING OK) indication is displayed if the extended communications card is present and
operating properly.
• (FAILURE)-0x0 indication is displayed if the extended communications card is present and
indicating a failure code.
088 Config. Logic
Equation Error
X
--- View NA NA NA NA NA
•Provide a display of 0 when there are no configurable logic errors and 1 when one or more
configurable logic errors exist.
089 Activate
Contact Output 1
X
--- View Modify NA NA 0 1
•Enables activation of discrete output contact 1.
•If value is 0, it can be changed to 1 and then back 0.
•If value is 1 because its activation is being driven by a logic equation, attempting to
change it to 0 will display (CANNOT OVERRIDE).
089 Activate
Contact Output 2
X
--- View Modify NA NA 0 1
•See description of Activate Contact Output 1.
089 Activate
Contact Output 3
X
--- View Modify NA NA 0 1
•See description of Activate Contact Output 1.
089 Activate
Contact Output 4
X
--- View Modify NA NA 0 1
•See description of Activate Contact Output 1.
090 CI1 = Inactive
CI2 = Inactive
CI3 = Inactive
CI4 = Inactive
--- View NA NA NA NA NA
•Provides a status of the auxiliary input contacts and will display the status as Inactive
or Active.
69
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
