Ecotech TRT Series User Manual

5.5 SIGNS
SeeTable1‐3:Symbolsconcerningsafetyforthemeaningofthesymbols.
ONTOPOFTHEMACHINETHISFIGUREISFOUND:


Figure5‐2:Adhesivelabellocatedonthemachine


ATTENTION!!!Thismachineisequippedwithsharpcuttingcomponents;thereforekeephandsandfeeta
safedistanceawayfromthese.Neverperformanyproceduresonthemachinewhilstitisrunning.


Itisrecommendedtonot workinareaswithgravel,rocks and/orforeignobjects onthegroundthatmaybeprojectedbythe
cuttingbladesmakingitextremelydangerousforpersonsorthingsinthevicinityoftherunningmachine.Keepallpersonnelat
least15metresawayfromthe
machine.Theoperatorshallalwayswearaprotectivefacemaskandasnecessaryrubberboots
aswell.


ATTENTION!!!Alwayskeepthehandsatasafedistancefromtheoscillatingmechanismonthemachineasit
caneasilycrushthefingers.


APPLICATIONOFTHESEREGULATIONSISNOTAWASTEOFTIME!
THESEREGULATIONSCONTRIBUTETOKEEPINGPERSONSANDTHINGSFROMIRREPARABLEHARMAND
ENSUREOPERATORSAFETY.

5.6 RESIDUALRISKS
Noise:alwayswearearprotection.
Vibrations:thesehavebeenreduced byusinganti‐vibrationgripsonthe110and135models.
It
isrecommendedthatonetakeregularbreaksduringworktime.Donotusethemachineformorethan8hoursinaday.


6 MACHINEUSE
Dearcustomer,wethankyouforthetrustyouhavegivenECOTECHITALIA.Weareconfidentthatuseofthisnewmachinewill
fullyfulfilyourrequirements.
Forthe purposeof obtainingoptimumapplicationandefficient maintenanceof themachineovertime,pleasereadallofthe
directionsandwarningsdescribed
inthisbooklet,whichmustalwaysbekepttogetherwiththemachine.


BEFORESTARTINGUPTHEMACHINEREADTHEUSEINSTRUCTIONMANUALTHOROUGHLY!

6.1 ADJUSTMENTS


Model
Adjustment TRT60 TRT60Swing TRT110 TRT110Swing TRT135 TRT135Swing
Cutting
height
Loosenthetwoknobsandpushtheslide
downwardsifthecuttingheightistobe
raised;raisetheslideupwardstolowerthe
cuttingheight,thentightendownthetwo
knobs.
Themachinecanbeadjustedtofourdifferentcuttingheights.Toadjustthecutting
heightremovethe
twoscrewsontheslidesandpositionthemattheholes
correspondingtothenewcuttingheight.

Plate
discharge
Ifworkinginveryhigh,thickorwetgrass,
loosenthetwoknobsandliftthesliding
partitionlocatedonthebackofthecutting
platetofacilitatethedischargeofthecut
grass.Ifinsteadthecutgrassistobeshredded
evenmore,shiftthepartitiondownwards.

Thentightendownthetwoknobs.
N/A
Speed Setspeed1.3
Km/h
Set thespeedchanger
controlleverontheleft
Selecttheoperationalspeedusingthespecificlever(Figure3‐2no.8).Thegearsare
distributedasfollows:Therearmostpositionoftheleverisreve rse;thefirstcatch
