Ecotech TRT Series User Manual

6.2.2 WORKINGONASLOPE(onlyontheSwingversion)

TRT60Swing
Whenworkingonslopingground,itisnecessarytowidenthetrackofthewheels.

Tocarryoutthisoperation,raisethesafetyspringoffofthepinand
removethepin(seefigure).Slideoutthesemi‐axleandlocateitin
correspondencetothesecondhole,thenreplacethepinandtherelative
safetyspring.Engagetheparkingbrakelocatedontopofthe

transmissioncasing.

Figure6‐4:WheellockingpinTRT60

Atthispoint,unlockthemotor,movingtheleveronthehandlebar
backwards(Figure6‐5:Handlebarsno.1),settheinclinationangleofthe
machineaccordingtotheslopeonthegroundonwhichtheworkistobe
doneuntilthemotorisonthelevel,horizontally,thenlock
themotor
shiftingthesameleverforward.makesurethatthelockingpin(Figure
6‐6:LockingPin)ispositionedinoneofthethreeseatstotherightorto
theleft.
Figure
6
‐5:Handlebars

Figure
6
‐
6
:LockingPin

Nowthemachineisreadyforwork.

Toinverttheworkingdirectionontheslope,unlockthelever(Figure
6‐7:Handlebarsno.1),holditbalancedwiththehandlebars
rotatethemachine180turninguphill,setthemachineinclinationangle
ontheoppositeside,repositioningthemotoronthelevel,thenrelocking
the machine with the
same lever and continuing the work in the
oppositedirection.

Figure
6
‐7:Handlebars




TRT110– 135Swing
Whenworkingonslopingground,itisnecessarytowidenthetrackofthewheels.

Toperformthisoperationputthemachineonitsstand(no.21),
Figure6‐8:Wideningthetrack

Raisethesafetyspringoffofthepinandremovethepin(no.20).Slide
outthewheelandlocatethehubincorrespondencetothesecond
holeonthesemi‐axle,thenreplacethepinandtherelativesafety
spring

Figure6‐9:WheellockingpinTRT110‐135
