Ecotech TRT Series User Manual


Atthispoint,unlockthemotor,holdingtheleftleverdownonthe
handlebar(Figure6‐10:Lefthandlebarno.2),settheinclinationangle
ofthemachineaccordingtotheslopeonthegroundonwhichthe
workistobedoneuntilthemotorisonthelevel,
horizontally,then
lockthemotorreleasingthesameleverincorrespondencewithone
ofthefourpositions.

Figure6‐10:Lefthandlebar
Nowthemachineisreadyforwork.
Toinverttheworkdirectiononaslopethefollowingsequencemust
befollowed:releasetheforwardmovementlever(Figure6‐10:Left
handlebarno.1),thiswaythemachineisstoppedandbraked,
positionthemotorinneutral(inthiswaythemotorwillbeinclinedfor
afew
secondstogetherwiththemachine),engagetheforward
movement(Figure6‐10:Lefthandlebarno.1)andatthesametime
pulltheuphillwheellockingleveralltheway(Figure6‐10:Lefthandle
barno.3orFigure6‐12:Righthandlebarno.6),inthis
waythe
machinewillturn180°onitselftowardtheuphillsideoftheslopeand
willthenbepositionedintheoppositedirectionreadyforwork.

Figure6‐11:Lefthandlebar Figure6‐12:Righthandlebar
Release theforward movement lever again (Figure 6‐10: Left handle bar no. 1), put the motor on thelevel againturning uphill, and at this point the
machineisreadytostartbacktoworkintheoppositedirection.
Table6‐2:Workingonaslope


Always start the work atthe bottom of the slope advancing sideways and on paralleltracks upwards to ensure better
dischargeofthecutgrassdownwards.Itisrecommendedthatoneworkfirstonlevelgroundorwithaveryslightslope
soastofamiliariseone'sselfwiththemachine’s operation.Steepslopesshouldbeworkedononlybyveryexperienced
operators.
Themachinehasbeendesignedtoworkonslopestransversallyandnotinperpendicular.
THEMANUFACTURERWILLNOT BELIABLEFOR ANYDAMAGECAUSED BY THEMOTORSEIZINGDUE TOINAPPROPRIATE
USEOFTHEMACHINE.


6.3 NORMALSTOP


Once the work has been completed, to stop the motor, put the gas lever on the
(Figure3‐1 no.6‐Figure 3‐2no.3) STOPposition and(orif themotor isequipped
usethestopswitchalwaysafterhavingallowedthemotorRPMtodroptoidle),
and
then,ifthereisone,turnthefuelcocktooff.
OntheTRT60Swingversionengagetheparkingbrake(seefiguretotheside).


Figure6‐13:Parkingbrake

6.4 EMERGENCYSTOP
Incaseofanymalfunctionduringworkoperations,simplyreleasethehandlebars:themachine
willstopforwardmovementand
thecuttingbladeswillstop.
Tostopthemotor,refertothepreviouspoint.

7 MAINTENANCE

7.1 MAINTENANCESTATUS


BEFOREperforminganymaintenanceoperationsonthemachine,turnoffthemotorandwaitfortheblades
tostopcompletely.


If the maintenance operations are not performed, there may be damage to the machine or injuries to the operator or
bystanders.Thesedamagesandinjuriesarenotcoveredbythewarranty.

 Dailymaintenanceistobeperformedbytheuser.
 Maintenanceoperationsafterthefirst20,100and
300hoursofoperationmustbeperformedatthereseller.
 Asktheresellertocheckthemachine,ifproblemsarise.
