CPU PnP Setup Page
This page helps you manually configure the CPU of this
mainboard. The system will automatically detect the type of
installed CPU and make the appropriate adjustments to these items
on this page.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
CPU PnP Setup
Manufacturer : Intel
Ratio Status : Locked
Ratio Actual Value : 23
Ratio CMOS Setting : 8
Auto Detect CPU and DRAM FREQU Auto
CPU Frequency Setting : 133 MHz
DRAM Frequency : 166 MHz
Manufacturer/
Ratio Status/
Ratio Actual
Value
These items show the brand, the Locked/
Unlocked ratio status, and the actual ratio of
the CPU installed in your system.
Ratio CMOS
Setting
This item shows the current ratio of the CPU
installed in your system.
Auto Detect
CPU and
DRAM
FREQU
When this item is enabled, it automatically
detects and shows the frequency of the CPU
and DRAM memory installed in your system;
when disabled, it can adjust the frequency of
the CPU and DRAM memory.
CPU
Frequency
This item shows the frequency of the CPU
installed in your system.
DRAM
Frequency
This item shows the frequency of the DRAM
in your system.
Sets the ration
between CPU Core
Clock and the FSB
Frequency. Note: If
an invalid ratio is
set in CMOS then
actual and setpoint
values ma
y
differ.
Hel
p
Item
