Page #37 background imageLoading...
Page #37 background image
31
Hardware Monitor Page
This page sets up some parameters for the hardware monitoring
function of this mainboard.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
Hardware Monitor Setup
*** System Hardware Monitor***
Vcore 1.504V
Vdimm 2.496V
Vivdd 1.792V
Vcc5V 5.107V
SB3V 3.296V
SYSTEM Fan1 Speed 0 RPM
SYSTEM Fan2 Speed 0 RPM
CPU Fan Speed 0 RPM
SYSTEM Temperature 32°C/89°F
CPU Temperature 41°C/105°F
CPU/System
Temperature
These items display CPU and system
temperature measurement.
FAN & Voltage
Measurements
These items indicate cooling fan speeds in
RPM and the various system voltage
measurements.
Load Optimal Defaults
This option opens a dialog box to ask if you are sure to install
optimized defaults or not. You press <Y>, and then <Enter>, the
Setup Utility loads all default values; or press <N>, and then
<Enter>, the Setup Utility does not load default values.
Note: It is highly recommend that users enter this option to
load optimal default values for accessing the best
performance.
Save Changes and Exit
Highlight this item and press <Enter> to save the changes that you
have made in the Setup Utility configuration. When the Save
Changes and Exit
dialog box appears, press Y to save and exit, or
press N to return to the main menu.
