EFI VUTEk 5r Series User Manual

Every 8 Hours
Document ID: OMM-00144-L VUTEk 3r & 5r Series Maintenance Guide 27
PPE Items: GLOVES NITRILE DISPOSABLE BOX LARGE
SAFETY GLASSES
Required Items: ISOPROPYL ALCOHOL (IPA)
WIPES 9X9 CLEAN ROOM
How-to Video:
Directions:
1. From the printer front end, click and hold the Carriage Right button, highlighted, Figure 4-6
, so that the ink sink is completely
exposed, Figure 4-7
.
2. Open the printer hood and insert the retaining pins into the LH and RH pin sockets.
4.4 Clean the ink sink.
CLICK TO PLAY
Figure 4-6 Front End Software Toolbar, Carriage Right button highlighted
Figure 4-7 Accessing the Ink Sink
