EFI VUTEk 5r Series User Manual

Monthly
Document ID: OMM-00144-L VUTEk 3r & 5r Series Maintenance Guide 54
PPE Items: GLOVES NITRILE DISPOSABLE BOX LARGE
SAFETY GLASSES
Required Items: WIPES 9X9 CLEAN ROOM
ISOPROPYL ALCOHOL (IPA)
SHOP VACUUM AND ATTACHMENTS
PHILLIPS SCREWDRIVER
How-to Video:
Directions:
1. Power down the printer.
2. Loosen exhaust vent housing captive screws.
3. Remove metal exhaust housing.
4. Dampen a lint-free wipe with IPA and fold in half.
5. Wipe down inside of exhaust housing and wipe down the printer sheet metal around the fan.
6. Vacuum the exhaust fan.
7. Repeat cleaning steps for remaining two exhaust vents.
7.3 Clean three main exhaust vents.
CLICK TO PLAY
Figure 7-4 Metal Exhaust Vent Housing (Left and Middle) and Vacuuming Exhaust Fan (Right)
