Technical Support - A.D.L. 38/83 599 74 12-51 Rev.00
9.2 Display of total operating time
This time is displayed with a sequence of two digits at a time: the first two digits indicate thousands and hundreds, the
second two digits indicate tens and units.
For example, if the operating time is 6,550 hours, the display will show the following sequence:
Phase 1 → Phase 2 → Phase 3 →
For two seconds
It displays: Hr
For two seconds, the following
digits are displayed:
ª thousands (6)
ª hundreds (5)
For the next two seconds the
following digits are displayed:
ª tens (5)
ª units (0)
At the end of phase three (after the tens and units are displayed), the cycle is repeated. To return to normal mode,
either: switch the appliance off or press a button or turn the selector knob.
