INSTALLATION INSTRUCTIONS | SMART LINE BOILING PAN
10 DOC N° ST0 9183-02 EN | 10-2018
Smart Line Boiling Pans with dual connection
PNC F. Mod.
Weight
Kg
Total power
kW
Voltage
V / neutral
conductor
Frequency
Hz
Max. phase
current
A
232222 + 928159 SM6B300 480 25 / 25 400 V / 3N 50/60 36 / 36
232226 + 928160 SM6V200 400 25 / 14.7 400 V / 3N 50/60 36 / 25
232227 + 928160 SM6V300 480 25 / 27.2 400 V / 3N 50/60 36 / 43
232230 + 928160 SM6P200 400 25 / 15.5 400 V / 3N 50/60 36 / 29
232231 + 928160 SM6P300 500 25 / 28 400 V / 3N 50/60 36 / 47
Smart Line Boiling Pans with ice water cooling
PNC F. Mod.
Weight
Kg
Total power
kW
Voltage
V / neutral
conductor
Frequency
Hz
Max. phase
current
A
232223 + 928153 SM6V50 180 15.8 400 V / 3N 50/60 27
232149 + 928164 SM6V80 270 23.3 400 V / 3N 50/60 38
232224 + 928154 SM6V100 280 24 400 V / 3N 50/60 39
232225 + 928155 SM6V150 400 31.5 400 V / 3N 50/60 51
232226 + 928156 SM6V200 400 39.7 400 V / 3N 50/60 62
232227 + 928157 SM6V300 480 52.2 400 V / 3N 50/60 80
3. TESTING / CERTIFICATION
All appliances are tested and certified according
to the relevant standards and approved engineer-
ing rules by internationally recognised testing bod-
ies. This guarantees that all internationally required
quality and safety standards have been met.
Each appliance features the CE marking on its
nameplate. All appliances have passed the test-
ing for protection class IP X5 (water protection). To
ensure continued compliance with this protection
class, all seals must remain in a perfect condition
and all components must be assembled proper-
ly after installation, repairs and maintenance work.
CE- DIRECTIVES
Boiling pans are
manufactured in compliance with relevant CE
directives and are CE labelled.
For details see CE declaration ST0 9186-61.
The machine is considered as an aggregate.The
unit consists of a CE-approved safety valve in
Category IV and a CE-approved vessel in Category
II.
