INSTALLATION INSTRUCTIONS | SMART LINE BOILING PAN
EN | 10-2018 DOC N° ST0 9183-02 19
11.7 Electrically heated boiling pans, other voltages on request
230V 3~50Hz* 400V 3~50/60Hz* 440V 3~50/60Hz* 480V 3~50/60Hz*
Model Volume
L
Max. phase
current A
Max. fuse
A
Max. phase
current A
Max. fuse
A
Max. phase
current A
Max. fuse
A
Max. phase
current A
Max. fuse
A
Q1 Q2 Q1 Q2
SM6B50 50 38 63 22 50 20 50 19 50
SM6V50 50 48 63 27 50 25 50 23 50
SM6V80 80 57 63 38 50 35 50 32 50
SM6B100 100 56 63 33 50 30 50 28 50
SM6V100 100 72 80 39 50 36 50 33 50
SM6P100 100 76 80 39 50 36 50 33 50
SM6B150 150 75 80 44 63 40 63 37 63
SM6V150 150 92 100 51 63 47 63 43 63
SM6P150 150 96 100 51 63 47 63 43 63
SM6B200 200 63 31 80 50 55 100 50 100 46 100
SM6V200 200 63 51 80 63 62 100 57 100 52 100
SM6P200 200 63 57 80 63 66 100 60 100 55 100
SM6B300 300 63 63 80 80 73 100 66 100 61 100
SM6V300 300 63 83 80 100 80 100 73 100 67 100
SM6P300 300 63 89 80 100 84 100 77 100 70 100
* The connection lead may be at most 32 mm² to have room in the connection terminals.
11.8 Steam heated boiling pans, other voltages on request
400V 3~50/60Hz* 440V 3~50/60Hz* 480V 3~50/60Hz*
Model Volume
L
Max. phase
current A
Max. fuse
A
Max. phase
current A
Max. fuse
A
Max. phase
current A
Max. fuse
A
SM6B50S 50 - - - - - -
SM6V50S 50 7 16 6 16 6 16
SM6B100S 100 - - - - - -
SM6V100S 100 9 20 8 20 8 20
SM6P100S 100 9 20 8 20 8 20
SM6B150S 150 3 16 3 16 3 16
SM6V150S 150 9 20 8 20 8 20
SM6P150S 150 9 20 8 20 8 20
SM6B200S 200 3 16 3 16 3 16
SM6V200S 200 10 20 9 20 9 20
SM6P200S 200 14 20 13 20 12 20
SM6B300S 300 3 16 3 16 3 16
SM6V300S 300 10 20 9 20 9 20
SM6P300S 300 14 20 13 20 12 20
* The connection lead may be at most 6 mm² to have room in the connection terminals.
