36 How to active
Now to connect the power cord into an outlet suitable: the device automatically turns
on in standby mode.
Warning: don’t deliver RF power before you have connected the device to the
antenna.
6.4 Factory settings
The device leaves the factory with the following default settings. If they match with the
needs of the user simply to set the desired power and place the device in RF ON. Inste-
ad, if there was a need to change the parameters, refer to “Main parameters setting” in
this section.
EXCITER TYPE
FACRTORY SETTINGS With Stereo Coder
(can operate in MPX
mode, Stereo mode,
and Mono mode)
With Stereo Coder
+ AES / EBU (can
operate in MPX mode,
Stereo mode, Mono
mode, and AES / EBU
mode)
With MPX (can ope-
rate in MPX mode
only)
Output power 0W 0W 0W
Frequency transmission 98.000 MHz 98.000 MHz 98.000 MHz
Sensitivity L,R inputs for
+/-75 kHz deviation
0dBm 0dBm 0dBm
Sensitivity MPX input
for +/-75 kHz deviation
0dBm 0dBm 0dBm
Sensitivity AUX input 0dBm 0dBm 0dBm
19kHz subcarrier stereo OFF (MPX input) OFF (MPX input) Not available
Preemphasis 0uS (linear) 0uS (linear) Not available
Clipper OFF OFF OFF
“NO AUDIO” alarm ON, with thresholds
setted for not inter-
vening (-45 dB for 5
minutes)
ON, with thresholds
setted for not inter-
vening (-45 dB for 5
minutes)
ON, with thresholds
setted for not inter-
vening (-45 dB for
5 minutes)
VSWR/ROS foldback OFF, protection by
threshold
OFF, protection by
threshold
OFF, protection by
threshold
Versions of these devices can have also the following boards:
EXCITER TYPE
PARAMETERS With TC/TS board With ETHERNET+PROFILES board
Interlock Externale jump -
ID Profile - 1
