39How to active
6.5.3 Audio level setting
To move the cursor to the field “LEV”, and press the encoder to make it editable.
Rotare the encoder to turn down the amplification (-15dB).
Apply the desired audio signal (as indicated in the next paragraph).
Increase slowly the gain until the Vu-meter reach the 0 dB level in accordance with the
audio signal peaks.
Confirm the value by pressing the encoder.
During operation the field CLIPPER should not light up, otherwise it means that the de-
viation is too high and therefore there is overmodulation.
6.5.4 Audio input setting
Depending on the audio signal type used to modulate, you must select the correspon-
ding input.
Rotate the encoder until highlight the second-last horizontal tab menu.
Press to make the field editable.
Now rotate the encoder to see other options:
6.5.4.1 MUTE
Used to mute all inputs. It is usually used during maintenance.
