EMC Connectrix DS-5300B User Manual

Nonport side of the DS-5300B
15
Introducing the Connectrix DS-5300B
Nonport side of the DS-5300B
Figure 2 shows the nonport side of the DS-5300B, which contains the
power supplies (including the AC power receptacle and AC power
switch) and fans.
Figure 2 Nonport Side of the DS-5300B
1
2
3 7
4
5 6
1 DS-5300B 5 Fan Assembly #2
2 Nonport Side of Switch 6 Fan Assembly #1
3 Power Supply #2 7 Power Supply #1
4 Fan Assembly #3

EMC Connectrix DS-5300B Specifications

General

Brand	EMC
Model	Connectrix DS-5300B
Category	Switch
Language	English
