Facility requirements

Specifications

Facility requirements

To ensure correct operation of the switch, the facility where the

switch is in use must meet the following requirements:

◆ Electrical:

• Primary AC input 100-240 VAC (switch autosenses input

voltage), 47-63 Hz

• Correctly wired primary outlet, protected by a circuit breaker

and grounded in accordance with local electrical codes

• Adequate supply circuit, line fusing, and wire size, as

specified by the electrical rating on the switch nameplate

• Electrical interference must be less than the levels stated in the

standards listed in Table 8 on page 56.

◆ Thermal:

• Air flows from the nonport side to the port side. A minimum

air flow of 47 cu ft/min (79.8 cu m/hr) available in the

immediate vicinity of the switch

• Ambient air temperature must not exceed 40º C (104º F) while

the switch is operating

◆ Environmental: Specifications are listed in Table 6 on page 55.

◆ Cabinet:

• Cabinet space of 2U in a EIA 19-in. cabinet

• All equipment in cabinet must be grounded through a reliable

branch circuit connection

• The additional weight of the switch must not exceed the

cabinet’s weight limits

• The cabinet must be secured to ensure stability in case of

unexpected movement
