Serial port specifications

Specifications

Serial port specifications

The serial port is located on the port side of the switch. The DS-5300B

uses an RJ-45 connector for serial port. An RJ-45 to DB9 adaptor cable

is also provided with the switch.

Note: To protect the serial port from damage, keep the cover on the port

when not in use.

The serial port can be used to connect to a workstation to configure

the switch IP address before connecting the switch to a fabric or IP

network. The serial port’s parameters are fixed at 9600 baud, 8 data

bits, and no parity, with flow control set to None.

Table 10 lists the serial cable pinouts.

Table 10 Serial cable pinouts

PIN Signal Description

1 Not supported NA

2 Not supported NA

3 UART1_TXD Transmit data

4 GND Logic ground

5 GND Logic ground

6 UART1_RXD Receive data

7 Not supported NA

8 Not supported NA
