Section 5: Module Removal and Installation
Module Removal and Installation
5.6 Power Swivel Module Installation
NOTE:
Refer to assembly drawing sheet 2 Detail "B". X- can be 1- or 9- items as required.
!
WARNING
Check overtravel position. The actuator must be in the appropriate overtravel position.
Conrm overtravel position by observing the guide block (1 - 30) is against the inner wall of
housing (1 - 10).
5.6.1 Push the guide block to the required side of the housing (1 - 10).
NOTE:
The guide block can be moved by inserting a long rod through either end of the housing
and pushing on the guide block.
5.6.2 Lubricate two spherical washers (X - 40), and one extension rod assembly (X - 50).
5.6.3 Install one spherical washer (X - 40) into the side of guide block (1 - 30).
NOTE:
The spherical side of washer (X-40) will be facing to the outside of guide block (1 - 30).
5.6.4 Install second spherical washer (X - 40) over threaded end of extension rod
assembly (X - 50).
NOTE:
The spherical side of the washer will go on the extension rod assembly facing the head of
the extension rod assembly.
5.6.5 Install extension rod assembly (X - 50) into right of guide block (1 - 30) and up
against the rst spherical washer (X - 40).
5.6.6 Install extension retainer nut assembly (X - 60) over extension rod assembly
(X - 50) and screw into guide block (1 - 30).
5.6.7 Tighten extension retainer nut assembly (X - 60) until extension rod assembly
(X - 50) cannot move. Back off the extension retainer nut assembly (X - 60) just
enough to allow for extension rod assembly (X - 50) to move freely.
