Emerson Bettis G4 Series User Manual

Installation, Operation and Maintenance Manual
VA-DC-000-1803 Rev. 2 July 2020
45
Section 6: Actuator Support Information
Actuator Support Information
Item No. Wrench Size Item Qty.
10 - 50 NUT, ACORN 3/8 - 16 UNC*HI CROWN* 5/8 Socket, Air Ratchet
20 - 10 - 210 PIPE PLUG, 3/8*5000#/SOLID* X 11/16 Socket, Air Ratchet
20 - 30 RLF VAL, KETA LRV-08-36/0207 3000 PSI
13/16 Body; 17 mm Nut;
3/16 Hex Adj. Screw
20 - 40 / 70 - 60 CHK VAL, KETA LCV-06-B-2.1 11/16 Socket, Air Ratchet
20 - 10 - 80 RTNR RING, INT 5/8, MC MSTR 99142A370 Inside Retainer Ring Pliers
30 - 100 SCR, SOC CP 3/8 - 16 UNC - 2A X 5/8 5/16 Hex Allen Wrench
20 - 10 - 120
GRV CLEVIS PIN W/ RTNR RING,
5/16 X 1 - 9/16
Retainer Ring Tool
20 - 10 - 180 PIPE PLUG, 3/8 NPT*SKT HD* 5/16 Hex Allen Wrench
20 - 10 - 190 PIPE PLUG, 1/4 NPT*SKT HD FLUSH* 1/4 Hex Allen Wrench
20 - 10 - 210
PIPE PLUG, 1/8 NPT*SKT HD FLUSH*,
7/8" TAPER
3/16 Hex Allen Wrench
20 - 10 - 240 SCR, SOC CP 1/4 - 20 UNC - 3A X 1/2 3/16 Hex Allen Wrench
20 - 260 CHK VAL, KETA LZFC-08-016-0.5 7/8 Socket
20 - 270 CHK VAL, KETA LCV-06-B-0.35 11/16 Socket
20 - 10 - 330 SCR, CSK FLT HD, 8 - 32 UNC - 1/4 Phillips Screwdriver
20 - 10 - 340 S/PIN .156 X 1.0 Drift Punch, Hammer
25 - 410 SCR, SOC CP #10 - 32 UNF - 3A X 3/8 LG 5/32 Hex Allen Wrench
25 - 430 BHCS 8 - 32 X .38 3/32 Hex Allen Wrench
25 - 440 NUT, STD HEX #8 - 32 HHS 1181CSS 11/32 Socket, Hand Ratchet
25 - 450 ACORN NUT, 5/16 - 18 UNC 9/16 Socket, Air Ratchet
20 - 20 - 10 PPAK SEAL, 12501000-250B*MOS2* PPAK Installation Tool
20 - 20 - 20 RD WIPR, 1.000*PARKER D1000* Rubber Mallet
20 - 10 - 170 BRG, PN M18 08DU04
Special design press pin,
Dead Blow Hammer
30 - 20 SCR, HEX CP 1/4 - 20 UNC - 2A X 1/2 3/16 Hex Allen Wrench
30 - 40 SCR, SOC CP 1/4 - 20 UNC - 3A X 1 3/16 Hex Allen Wrench
30 - 50 NUT, ELASTIC STOP 1/4 - 20 UNC*316SS* 7/16 Socket
30 - 100 SCR, FLT C'SK CP 3/8 - 16 UNC X 3/4 LG 7/32 Hex Allen Wrench
30 - 110 SCR, SOC CP 1/2 - 13 UNC - 3A X 1 LG 3/8 Hex Allen Wrench
6.10 M18 Tool Style and Wrench Size
Table 15. M18 Tool Style and Wrench Size
