Installation, Operation and Maintenance Manual
VA-DC-000-1803 Rev. 2
July 2020
41
Section 6: Actuator Support Information
Actuator Support Information
6.2 G01 Tool Style and Wrench Size
Table 7. G01 Tool Style and Wrench Size
Item No. Wrench Size Item Qty.
Location or
Description
Recommended
Tool Style
1 - 110 9/16” 6 Hex Cap Screws Socket
1 - 160 9/16” 4 Hex Cap Screws Socket
1 - 180 3/8” sq. 2 Stop Screws Open End or Adjustable
1 - 190 1 - 1/8” 2 Hex Jam Nuts Open End or Adjustable
3 - 20 3/8” 2 Tie Bar (ats) Open End or Adjustable
3 - 40 3/8” sq. 1 Piston Rod Male Drive Extension
3 - 90 1 - 1/8” 2 Standard Hex Nuts Socket
3 - 100 9/16” 4 Hex Cap Screws Socket
3 - 120 5/8” sq. 1 Pipe Plug Open End or Adjustable
3 - 130 3/16” 2 Socket Cap Screws Allen
7 - 40 3/8” sq. 1 Piston Rod Male Drive
7 - 90 9/16” 4 Standard Hex Nuts Socket
7 - 100 9/16” 4 Hex Cap Screws Socket
7 - 105 9/16” 4 Standard Hex Nuts Socket
7 - 115 9/16” 4 Hex Cap Screws Socket
7 - 120 9/16” sq. 1 NPT Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
Item No. Wrench Size Item Qty.
Location or
Description
Recommended
Tool Style
1 - 110 9/16” 6 Hex Cap Screws Socket
1 - 160 9/16” 4 Hex Cap Screws Socket
1 - 180 3/8” sq. 2 Stop Screws Open End or Adjustable
1 - 190 1 - 1/8” 2 Hex Jam Nuts Open End or Adjustable
3 - 20 3/8” 2 Tie Bar (ats) Open End or Adjustable
3 - 40 3/8” sq. 1 Piston Rod Male Drive
3 - 90 1 - 1/8” 4 Standard Hex Nuts Socket
3 - 100 9/16” 4 Hex Cap Screws Socket
3 - 120 5/8” sq. 1 Pipe Plug Open End or Adjustable
3 - 130 3/16” 2 Socket Cap Screws Allen
7 - 40 3/8” sq. 1 Piston Rod Male Drive
7 - 90 3/4” 4 Standard Hex Nuts Socket
7 - 100 9/16” 4 Hex Cap Screws Socket
7 - 105 9/16” 4 Standard Hex Nuts Socket
7 - 115 9/16” 4 Hex Cap Screws Socket
7 - 120 9/16” sq. 1 NPT Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
6.3 G2 Tool Style and Wrench Size
Table 8. G2 Tool Style and Wrench Size
