Section 6: Actuator Support Information
Actuator Support Information
Item No. Wrench Size Item Qty.
Location or
Description
Recommended
Tool Style
1 - 110 3/4” 16 Hex Cap Screws Socket
1 - 120 3/4” 4 Hex Cap Screws Socket
1 - 160 9/16” 8 Hex Cap Screws Socket
1 - 180 1 - 1/2” 2 Stop Screws Open End or Adjustable
3 - 20 3/4” sq. 2 Tie Bar (female square) Open End or Adjustable
3 - 40 3/4” sq. 1 Piston Rod Male Drive
3 - 90 3 - 1/2” 2 Heavy Hex Nuts Socket
3 - 100 1 - 5/16” 8 Hex Cap Screws Socket
3 - 120 1 - 5/16” sq. 1 Pipe Plug Open End or Adjustable
3 - 130 3/16” 2 Socket Cap Screws Allen
7 - 40 3/4” sq. 1 Piston Rod Male Drive
7-90 3 - 1/2” 8 Hex Nuts Socket
7 - 100 1 - 1/8” 8 Hex Cap Screws Socket
7 - 105 1 - 1/8” 8 Standard Hex Nuts Socket
7 - 115 1 - 1/8” 8 Hex Cap Screws Socket
7 - 120 15/16” 1 NPT Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
6.8 G8 Tool Style and Wrench Size
Table 13. G8 Tool Style and Wrench Size
6.9 G10 Tool Style and Wrench Size
Table 14. G10 Tool Style and Wrench Size
Item No. Wrench Size Item Qty.
Location or
Description
Recommended
Tool Style
1 - 110 3/4” 12 Hex Cap Screws Socket
1 - 120 3/4” 4 Hex Cap Screws Socket
1 - 160 9/16” 8 Hex Cap Screws Socket
1 - 180 1 - 1/4” 2 Stop Screws Open End or Adjustable
3 - 20 3/4” sq. 2 Tie Bar (female square) Open End or Adjustable
3 - 40 3/4” sq. 1 Piston Rod Male Drive
3 - 90 2 - 3/4” 2 Heavy Hex Nuts Socket
3 - 100 1 - 1/8” 8 Hex Cap Screws Socket
3 - 120 1 - 5/16” sq. 1 Pipe Plug Open End or Adjustable
3 - 130 3/16” 2 Socket Cap Screws Allen
7-40 3/4” sq. 1 Piston Rod Male Drive
7 - 90 1 - 1/2” 8 Hex Nuts Socket
7 - 100 1 - 1/8” 8 Hex Cap Screws Socket
7 - 105 1 - 1/8” 8 Standard Hex Nuts Socket
7 - 115 1 - 1/8” 8 Hex Cap Screws Socket
7 - 120 15/16” 1 NPT Pipe Plug Open End or Adjustable
13 3/4” 2 Vent Check Assembly Open End
