To stop a jog operation, perform one of the following:
Remove the jog command.
Press the STOP button on the keypad.
Activate Emergency Stop using the keypad programmable inputs.
Jog will recommence at the end of a restart delay if the jog command is still present. All other commands except the above, will be
ignored during jog operation.
7.5 Inside delta operation
Adaptive Control, Jog, Brake and PowerThrough functions are not supported with inside delta (six-wire) operation. If these
functions are programmed when the starter is connected inside delta the behaviour is as given below:
Table 7-5 Inside delta compatibility
The starter performs a constant current start.
The starter performs a TVR soft stop if Pr 2I Stop Time is >0 secs. If Pr 2I is set to 0 secs the
starter performs a coast to stop.
The starter issues a warning with the error message Unsupported Option.
The starter performs a coast to stop.
The starter trips with the error message Lx-Tx Shorted.
For more information on PowerThrough, see Pr 15D Shorted SCR Action.
When connected in inside delta, current imbalance is the only phase loss protection that is active during run. Do not
disable current imbalance protection (Pr 5C) during inside delta operation.
