8.3 Adjustment lock
You can lock the Programming Menu to prevent users from altering parameter settings. The adjustment lock can be turned on and
off using Pr 15C.
To lock the programming menu:
1. Open the Programming Menu.
2. Open the Advanced Menu.
3. Select 'Restricted'
4. Enter the Access Code
5. Select Pr 15C Adjustment Lock.
6. Select and store 'Read Only'
If a user attempts to change a parameter value when the adjustment lock is active, an error message is displayed:
Access Denied
Adj Lock is On
8.4 Load defaults
Load Defaults restores the starter to the factory default settings for all parameters except Pr 9A Language. This does not reset the
access code.
To load defaults:
1. Open the Programming Menu and select Setup Tools. Enter the access code.
2. Scroll to the required function and press the M button.
Load Defaults
Load Backup
Save User Set 1
3. At the confirmation prompt, select YES to confirm or NO to cancel and then M to
load/save the selection.
Load Defaults
No
Yes
When the action has been completed, the screen will briefly display a confirmation
message, then return to the status screens.
8.5 Quick setup details
To access the Quick Setup Menu, press the M button and select Quick Setup Menu.
The Quick Setup Menu makes it easy to configure the Digistart IS for common applications. The Digistart IS selects the parameters
relevant to the application and suggests a typical setting, and you can adjust each parameter to suit your exact requirements.
Always set Pr 1A Motor Full Load Current to match the motor's nameplate full load current. The suggested value is the starter's
minimum full load current.
Table 8-2 Quick setup menu
Application
Parameter
Pr Number
Suggested value
Pump Centrifugal
Motor Full Load Current
Start Mode
Adaptive Start Profile
Start Ramp Time
Stop Mode
Adaptive Stop Profile
Stop Time
1A
2A
2E
2D
2H
2K
2I
Model dependent
Adaptive Control
Early Acceleration
10 seconds
Adaptive Control
Late Deceleration
15 seconds
Pump Submersible
Motor Full Load Current
Start Mode
Adaptive Start Profile
Start Ramp Time
Stop Mode
Adaptive Stop Profile
Stop Time
1A
2A
2E
2D
2H
2K
2I
Model dependent
Adaptive Control
Early Acceleration
5 seconds
Adaptive Control
Late Deceleration
5 seconds
Fan Damped
Motor Full Load Current
Start Mode
Current Limit
1A
2A
2B
Model dependent
Constant Current
350%
Fan Undamped
Motor Full Load Current
Start Mode
Adaptive Start Profile
Start Ramp Time
Excess Start Time
Locked Rotor Time
1A
2A
2E
2D
5A
1C
Model dependent
Adaptive Control
Constant Acceleration
20 seconds
30 seconds
20 Seconds
