Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
July 2017
27
Note
Depending on the control system you are using, an HF340 HART filter may be needed to allow HART communication. The HART
filter is a passive device that is inserted in field wiring from the HART loop. The filter is normally installed near the field wiring
terminals of the control system I/O. Its purpose is to effectively isolate the control system output from modulated HART
communication signals and raise the impedance of the control system to allow HART communication. For more information on
the description and use of the HART filter, refer to the HF340 HART filter instruction manual (D102796X012
). To determine if your
system requires a HART filter refer to the DVC6200 HW1
, DVC6200 HW2, or DVC6200 SIS instruction manual, or contact your
Emerson sales office
or Local Business Partner.
5. Replace and hand tighten the cover on the terminal box.
6. For applications that require a Position Transmitter or Discrete Switch (page 28), Remote Feedback
Mounting (page 30), and/or THUM
™
Adapter (page 32), proceed to the appropriate page. For DVC6200 SIS
applications proceed to Special Instructions for DVC6200 SIS on page 35. Otherwise, proceed
to Step 4—Configure the Digital Valve Controller on page 33.
To Next Page
