Emerson FPCSK User Manual

20

Chapter 4 - Programming
4.1 Commander HSK Required Programming
The following Commander HSK parameters must be set to the values shown
in order to ensure proper operation of the Electronic bypass package. These
settings are pre-programmed from the factory, DO NOT change any of these
values unless directed to by Emerson Control Techniques technical
support. Note these parameters must be programmed in the sequence
shown.
Parameter
Menu 0
Equivalent
Description Setting Units
1.51 27 Power-up keypad reference LASt -
2.04 30 Ramp mode select FASt -
2.06 - S ramp enable On -
2.07 - S ramp acceleration limit 60 s/100 Hz
5.14 41 Voltage mode select Fd -
6.12 - Enable stop key On -
7.06 16 Analog input 1 mode (terminal T2) 4-.20 -
8.22 - Terminal B4 digital input destination 6.39 menu.param
8.23 - Terminal B5 digital input destination 6.30 menu.param
8.24 - Terminal B6 digital input destination 10.33 menu.param
8.25 - Terminal B7 digital input destination 0.00 menu.param
9.04 - Logic function 1 source 1 8.03 menu.param
9.06 - Logic function 1 source 2 8.05 menu.param
9.10 - Logic function 1 destination 1.43 menu.param
6.40 - Enable sequencer latching Off -
4.2 Affinity BA Required Programming
The following Affinity BA parameters must be set to the values shown in order
to ensure proper operation of the Electronic bypass package. These settings
are pre-programmed from the factory,
DO NOT change any of these values unless directed to by Emerson
Control Techniques technical support. Note these parameters must be
programmed in the sequence shown.
Parameter
Menu 0
Equivalent
Description
Setting
Units
Fan Pump
1.14 0.05 Reference selector A1.A2 A1.A2 -
1.51 - Power-up keypad reference LASt LASt -
1.52 - Enable hand/off/auto keypad mode 1 1
2.06 - S ramp enable On On -
2.07 - S ramp acceleration limit 60 10 s/100 Hz
6.12 - Enable stop key On On -
6.49
- Disable multi-mode drive module, no
storing on trip
On On -
7.10 - T5/6 analog input 1 destination 0.00 0.00 menu.param
7.14 0.20 T7 analog input 2 destination 1.36 1.36 menu.param
