21
8.22 - T25 digital I/O 2 source/destination 10.33 10.33 menu.param
8.23 - T26 digital I/O 3 source/destination 6.30 6.30 menu.param
8.24 - T27 digital I/O 4 source/destination 1.54 1.54 menu.param
8.25 - T28 digital I/O 5 source/destination 1.41 1.41 menu.param
9.04 - Logic function 1 source 1 8.03 8.03 menu.param
9.06 - Logic function 1 source 2 8.06 8.06 menu.param
9.10 - Logic function 1 destination 1.43 1.43 menu.param
4.3 Commander HSK Recommended Programming
The following is a list of parameters that should be programmed at the time of
Start-up. These values are recommendations only, actual settings should be
determined by the application requirements, conditions, and the policies of the
equipment owners. Refer to the Commander SK Advanced User Guide for a
full parameter list and explanation.
Parameter
Menu 0
Equivalent
Description Setting Units
1.06 02 Maximum set speed 60 Hz
1.07 01 Minimum set speed 0 Hz
2.11 03 Acceleration rate 1 50.0 s/100 Hz
2.21 04 Deceleration rate 1 75.0 s/100 Hz
5.07 06 Motor rated current From Motor A
5.08 07 Motor rated speed From Motor RPM
5.09 08 Motor rated voltage From Motor V
5.13 32 Dynamic V to f select OFF -
6.09 33 Catch a spinning motor select 1 -
7.33 36 Analog output control (terminal B1) Fr -
8.41 35 Digital output control (terminal B2) n=0 -
11.44 10 Security status L3 -
Note: If the analog speed reference into VFD terminal T2 is 0–10 Vdc instead
of the default 4–20 mA, parameter 7.06 (menu 0 parameter 16) must be
changed to VoLt (6).
4.4 Affinity Recommended Programming
The following is a list of parameters that should be programmed at the time of
Start-up. These values are recommendations only, actual settings should be
determined by the application requirements, conditions, and the policies of the
equipment owners. Refer to the Affinity User Guide for a full parameter list and
explanation.
