7.4 Startup Checklist – VFD
Customer: Installation Site: Date: Sales Order #: Service Order #: Serial#: Model #:
Application Description:
Checklist
(Note any discrepancy in checklist findings in comment field)
Line voltage and current
Motor nameplate
V
L12: VL23: VL31:
Hp:
FLA: PF:
I
L1: IL2: IL3:
RPM:
LR
Code:
Eff:
Parameters changed from factory
default and new value
Par Value Par Value Par Value Par Value Par Value Par Value
Comms Address:
Comments:
No Yes
Unit ready for startup with all connections made and control interface, power and load available?
Enclosure inspected for shipping damage, physical integrity; door, latch and lock operation?
Line and motor power connections tight and made to proper terminals with satisfactory clearances?
Control wiring present and made to proper terminals and pull apart terminal blocks fully engaged?
Physical installation and wiring conform to factory drawings or manuals as required?
Control devices, contactors, overloads, breakers, switches, operating mechanisms, interlocks, OK?
Separate ac line reactor, dc link reactor, or dynamic brake module/resistor, if supplied, properly installed?
Basic settings, application specific settings, and purchased options setup completed?
Site Contact Signature: ______________________________ Provide copy to factory and site contact
