Menu Explanation
Device Status
The device status menu lists all of the devices assigned to all the loops. Devices can be scrolled through
using the rotary controller. The allocated loop and address numbers are shown, along with the device
type and its current status. The devices are displayed in Loop and Address number order.
Front Display Device Status
A typical display is shown below;
The descriptions for the shown display are as follows;
L1; In this example this indicates that the device is assigned to loop 1.
A003; In this example this indicates that the device is assigned to address 003.
L; This eld indicates the devices current status*.
Optic; This eld indicates the device type†.
* Available current device statuses are:
L; Logged On to the RCC and in normal condition.
U; Device is unassigned to an RCC.
C; Combined sounder / detector logged on to the RCC and in normal condition. Note: such device shall
hold two loop addresses. (The rst for its sounder and the next for its detector).
!; Fault present. (See fault status descriptions).
; Fire present.
; Pre alarm present.
† Available device type elds are:
Optic; Optical Detector
Sound; Sounder Device
I/O; Input/Output Device
Multi; Multisensor Detector
Heat; Heat Detector
Ht Heat; High Temperature Detector
MCP; Manual Callpoint
L1 A003 L Optic
Page 18 of 40©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM
