Hub/RCC Status; when entered, this menu lists the Radio Hub and all of the Radio Cluster
Communicators added to the system. These can be scrolled through using the rotary controller. The
allocated loop and address numbers are shown along with their current status.
Front Display Hub/RCC Options Hub/RCC Status
A typical display is shown below;
The descriptions for the shown display are as follows;
L1; this example indicates that the device is assigned to loop 1.
A003; this example indicates that the device is assigned to address 003.
L; this eld indicates the devices current status*.
RCC; this eld indicates the device type†.
* Available options are:
L; logged On to the Radio Hub and in normal condition.
U; RCC is unassigned to the Radio Hub.
!; a fault is present. (See fault status descriptions).
† Available options are:
RCC01; Radio Cluster Communicator numbered from 01-31
Hub; Radio Hub
L1 A003 L RCC01
Page 25 of 40©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM
