Page 31 of 40
Currently Used
Once entered, currently used channels for ‘RCC RCC Ch’ and ‘Device RCC Ch’ will be accessible.
RCC RCC Ch; channels being used for the RCC to RCC communication can be viewed by selecting the
following:
Front Display Radio Channels Currently Used RCC RCC Ch
Device RCC Ch; channels being used for the Device to RCC communication can be viewed by selecting
the following:
Front Display Radio Channels Currently Used Device RCC Ch Select relevant RCC no
Manual Select
Once entered, options for ‘RCC RCC Ch’ and ‘Device RCC Ch’ manual selection of channels will be
available.
RCC RCC Ch; RCC to RCC communication channels can only be manually changed whilst no RCCs are
on the system. Care must be taken to select one channel from the High band and one from the Low
band as previously detailed within in the Radio Channels section:
Front Display Radio Channels Manual Select RCC RCC Ch
For example:
Radio Hub to RCC Communication path Low Band Ch1, High Band Ch32
Device RCC Ch; device to RCC communication channels can only be manually changed whilst no
devices are added to the RCC. Care must be taken to select one channel from the Low band and one
from the High band as described in the Radio Channels section:
Front Display Radio Channels Manual Select Device RCC Ch
For example:
Device to RCC Communication path Low Band Ch 4, High Band Ch 29
©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM
