Quick System Programming
This quick system programming guide provides a recommended procedure into the installation and
programming of the EMS FireCell Radio System.
Before commencing with the installation, the survey report should be available detailing where the
control panel and wireless infrastructure is to be tted.
Ensure the correct equipment is to be tted at the designated location, see Equipment Familiarisation
section.
Ensure the Loop and Address numbers which are to be allocated to the devices and wireless control
equipment are known, as they are required when programming. The Radio Hub defaults to Loop 1
Address 1. If this is to be changed, then see the ‘Set Hub Address’ within the Menu Explanation section.
When using the quick guide the following symbols are shown for the internal controls on the Radio Hub.
All programming is undertaken for the system at the Radio Hub.
BACK
= Turn & Press Rotary Button to select relevant menu option.
= Press the Back Button to exit the menu.
Panel & Hub Installation
The Control Panel and the Radio Hub must be installed in their designated locations.
Installation instructions are supplied with each unit and should be followed.
RCC Installation & Programming
The RCCs should be installed installing in designated locations.
Installation instructions are supplied with each unit and should be followed.
A unique ident number is shown on the side of each RCC, this should be recorded as it is required when
adding the RCC to the Radio Hub.
From Front Display Hub/RCC Options Add RCC Select Desired Signal Path *
Select Desired Loop & Device Address Add By Ident Add Dev 12345 Y? ’Enter the RCCs ident
New Addr L1 A002.
To Exit
* = If the RCC’s signal path is to be direct to the Radio Hub then Radio Hub should be selected. If the RCCs
signal path is via another RCC, then the relevant RCC will need to be selected. Each option can be chosen by
turning the rotary switch.
BACK
Page 8 of 40©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM
