EMS FireCell FC-323-CA1 User Manual

Equipment Familiarisation
Wireless Call Point
Wireless Detector Base
Wireless Sounder & Detector Base
Wireless Sounder Base
Page 6 of 40©2019 EMS Ltd. All rights reserved. MK98 Iss17 05/04/2019 AJM
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
Log on button
Power jumper
Status
LED
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
Power jumper
www.emsgroup.co.uk
Wireless Detector Base
PRESS HERE TO
LOG ON
IDENT
Log on button
Status LED
www.emsgroup.co.uk
Combined Sounder
and Detector Base
PRESS HERE TO
LOG ON
IDENT
!
ON
1
2
3
4
4 Way Conguration DIL Switch
(Switch 1 ON = POWER ON)
ON
1
2
3
4
*
* Note; as viewed at 180
degree device rotation.
Log on button
Status LED
Ident Number
RevX DD/MM/YY
1d872
Ident Number
RevX DD/MM/YY
1d872
Ident Number
RevX DD/MM/YY
1d872
www.emsgroup.co.uk
Wireless Sounder Base
PRESS HERE TO
LOG ON
IDENT
SIZE C SIZE C SIZE C
SIZE AA
SIZE AA
SIZE AA
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
Power jumper
Log on button
Status LED
Ident Number
RevX DD/MM/YY
1d872
