13
The only clearance the HPAC 2.0 requires is 3.5” on the top of the unit to the ceiling so that the air can be returned to the unit
through the grille on the top.
We highly recommend as close to 8” as possible from the top of the unit to the ceiling for ease of changing the filter and
accessing the unit.
The HPAC should not touch the wall on either side as it will vibrate slightly during operations and that will create noise, even
1/2” will suce. However, we highly recommend 2.5” on the side for easier access.
We recommend mounting HPAC 2.0 at least 1” from the floor and closer to 2” to allow the floor to be cleaned under the unit.
WARNING
FALLING OBJECT HAZARD
Failure to mount the unit securely can result in property damage,
injury or death.
3.5”
2.5”
2.5”
1.0”
REQUIRED CLEARANCE
