CHECKLIST
Pre Installation
Determine type of exterior louver from approved list of louvers
Determine location of unit
Determine type of condensate drain (if used in heat mode)
Check for proper electrical connection
Installation
Template is 100% level
Holes for vents drilled in correct position
Sealed around exterior louvers
Condensate drain connected (if used for heating)
Wall bracket is securely hung - at least 2 screws are in cement or wood, other 4 screws are TOGGLER® brand,
SNAPTOGGLE® Heavy-Duty Toggle Bolts model number BB or BBS in 1/4”.
Compressor is unlocked
Approved exterior grilles are installed
Anti-lift bracket is fastened to wood or with TOGGLER® brand, SNAPTOGGLE® Heavy-Duty Toggle Bolts model
number BB or BBS in 1/4”
Unit is 100% level on both horizontal and vertical axises
Wall controller installed*
All packing materials disposed
Guide given to owner
System tutorial to owner
* For models with wall controller instead of on-board controller
