Epson EB-2247U User Manual

Projector Network Settings - Network Menu
134
Settings on the Network menu let you view network information and set up
the projector for controlling over a network.
When you set Network Protection to On in the Password Protection screen,
you cannot change the network settings. Set Network Protection to Off first.
Setting Options Description
Wireless Mode * Screen Mirroring
On
Wireless LAN On
Both Settings Off
Configures your wireless settings.
Select Screen Mirroring On to project
with the Screen Mirroring features. Select
Wireless LAN On when connecting the
projector and a computer over a wireless
LAN. If you do not want to connect via
wireless LAN, turn it off to prevent
unauthorized access by others.
Wireless Mode ** Wireless LAN On
Off
Configures your wireless settings.
Select Wireless LAN On when
connecting the projector and a computer
over a wireless LAN. If you do not want
to connect via wireless LAN, turn it off to
prevent unauthorized access by others.
Setting Options Description
Screen Mirroring
Info *
Display Name
MAC Address
Region Code
Channel
Connected Device
Displays Screen Mirroring status and
details.
Available when you have set Wireless
Mode to Screen Mirroring On.
Screen Mirroring
Settings *
To Screen
Mirroring Settings
menu
Configures your Screen Mirroring
settings.
Net. Info. -
Wireless LAN
Connection Mode
Wireless LAN Sys.
Antenna Level
Projector Name
SSID
DHCP
IP Address
Subnet Mask
Gateway Address
MAC Address
Region Code
IPv6
Displays wireless network status and
details.
Available when you have set Wireless
Mode to Wireless LAN On.
The following settings are displayed
when you select the IPv6 option.
• IPv6 Address (Manual)
• IPv6 Address
• Prefix Length
• Gateway Address
• IPv6 Address (Auto)
• Temporary Address
• Link-local Address
• Stateless Address
• Stateful Address

Epson EB-2247U Specifications

General

Matrix size	0.67 \
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.5 - 8.9 m
Vertical scan range	200 - 240 Hz
Projection technology	3LCD
Contrast ratio (dynamic)	-
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2410 ANSI lumens
Lamp power	230 W
Light source type	Lamp
Lamp power (economic mode)	- W
Service life of light source	5500 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.39 - 2.23:1
Zoom capability	Yes
Focal length range	23 - 38.4 mm
Aperture range (F-F)	1.5 - 2
3D	No
Color modes (2D)	Cinema, Dynamic
Video processing	10 bit
Video color modes	Blackboard, Dynamic, Photo, Presentation, sRGB
Composite video in	1
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	29 dB
RMS rated power	16 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	331 W
Power consumption (economy mode)	227 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Bundled software	Epson Projector Management Software, EasyMP Multi PC Projection
Pallet width	800 mm
Pallet height	6870 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	72 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	282 mm
Width	309 mm
Height	90 mm
Weight	3200 g
Package depth	390 mm
Package width	170 mm
Package height	385 mm
Package weight	4.39 g
