Epson EB-2247U User Manual

Projector Network Settings - Network Menu
136
Setting Options Description
Basic Wireless LAN Sys. Sets the communication method between
the projector and the mobile device.
You can select the following methods:
• 802.11a/g/n/ac
• 802.11a/g/n
• 802.11g/n
The available methods vary depending
on countries and regions.
Adjust Image
Quality
Adjusts the screen mirroring
speed/quality.
When you want to increase image
quality, select a small number. When you
want to increase processing speed, select
a large number.
Connection Mode Selects the type of WPS (Wi-Fi Protected
Setup) when you connect to the network
wirelessly. Select PIN to improve the
connection security. If your mobile
device supports only the PBC
connection, select PIN/PBC.
Available when you have set Operation
Mode to Basic.
Extended Available when you have set Operation
Mode to Extended.
Meeting Mode Selects the type of meeting.
• Interruptions OK: lets you connect to
another mobile device during Screen
Mirroring projection.
• No Interruptions: lets you exclusively
connect to one device.
Channel Selects the wireless channel used by
Screen Mirroring.
Display Display PIN Code Set to On to display the eight-digit PIN
code on the projected image when
projecting input sources other than
Screen Mirroring.
Setting Options Description
Display Device
Name
Set to On to display the newly connected
device name on the projected image
when projecting input sources other than
Screen Mirroring.
Reset — Resets all adjustment values on the
Screen Mirroring Settings menu to their
default settings.
Network Menu - Basic Menu
Settings on the Basic menu let you select the basic network settings.
s Network > Network Configuration > Basic

Epson EB-2247U Specifications

General

Matrix size	0.67 \
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1.5 - 8.9 m
Vertical scan range	200 - 240 Hz
Projection technology	3LCD
Contrast ratio (dynamic)	-
Contrast ratio (typical)	15000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2410 ANSI lumens
Lamp power	230 W
Light source type	Lamp
Lamp power (economic mode)	- W
Service life of light source	5500 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.39 - 2.23:1
Zoom capability	Yes
Focal length range	23 - 38.4 mm
Aperture range (F-F)	1.5 - 2
3D	No
Color modes (2D)	Cinema, Dynamic
Video processing	10 bit
Video color modes	Blackboard, Dynamic, Photo, Presentation, sRGB
Composite video in	1
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	29 dB
RMS rated power	16 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	331 W
Power consumption (economy mode)	227 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Bundled software	Epson Projector Management Software, EasyMP Multi PC Projection
Pallet width	800 mm
Pallet height	6870 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	72 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	282 mm
Width	309 mm
Height	90 mm
Weight	3200 g
Package depth	390 mm
Package width	170 mm
Package height	385 mm
Package weight	4.39 g
