Page #151 background imageLoading...
Page #151 background image
Copying Menu Settings Between Projectors (Batch Setup)
151
f
Disconnect the power cord from the projector to which you want to
copy settings, and check that all of the projector's indicators have
turned off.
g
Connect the USB flash drive containing the saved batch setup file to the
projector's USB-A port.
h
Hold down the [Menu] button on the remote control or the control
panel and connect the power cord to the projector.
i
When all of the projector's indicators turn on, release the [Menu]
button.
When all of the indicators start flashing, the settings are being written.
When writing is finished, the projector turns off.
Caution
Do not disconnect the power cord or the USB flash drive from the projector
while the file is being written. If the power cord or drive is disconnected,
the projector may not start correctly.
j
Remove the USB flash drive.
Transferring Settings From a Computer
You can copy menu settings from one projector to another of the same model
by connecting the computer and projector with a USB cable.
a
You can use this batch setup method with the following operating
system versions:
Windows Vista and later
OS X 10.7.x and later
a
Disconnect the power cord from the projector, and check that all of the
projector's indicators have turned off.
b
Connect a USB cable to the computer's USB port and to the projector's
USB-B port.
c
Hold down the [Esc] button on the remote control or the control panel
and connect the power cord to the projector.
d
When all of the projector's indicators turn on, release the [Esc] button.
The computer recognizes the projector as a removable disk.
e
Open the removable disk icon or folder, and save the batch setup file to
the computer.
a
The file name for the batch setup file is PJCONFDATA.bin. If
you need to change the file name, add text after PJCONFDATA
using only alphanumeric characters. If you change the
PJCONFDATA section of the file name, the projector may not be
able to recognize the file correctly.
f
Eject the USB device (Windows) or drag the removable disk icon to the
Trash (Mac).
g
Disconnect the USB cable.
The projector turns off.
h
Disconnect the power cord from the projector to which you want to
copy settings, and check that all of the projector's indicators have
turned off.
i
Connect the USB cable to the computer's USB port and to the
projector's USB-B port.
j
Hold down the [Menu] button on the remote control or the control
panel and connect the power cord to the projector.
k
When all of the projector's indicators turn on, release the [Menu]
button.
