Epson L8180 User Manual

184
Print settings Available
options
Description
Clear All Settings Yes Restores all paper and print settings to their defaults.
No
Parent topic: Viewing and Printing Photos
Related tasks
Viewing and Printing Photos From the LCD Screen
Printing Photo Layouts from a Memory Card with a Template
You can print one or more photos from a memory card in special layouts on various sizes of photo paper.
You can have the product automatically place the photos in the layout or you can manually place them
yourself.
1. Load photo paper in your product.
2. Insert a memory card into your product's memory card slot.
Note: If Auto Selection Mode is turned on in the Guide Functions menu, select to function index
when you see the information screen.
3. Select the home icon, if necessary.
4. Select Print Photos.
You see a screen like this:

Epson L8180 Specifications

General

Print Technology	Inkjet
Maximum Print Resolution	5760 x 1440 dpi
Ink Type	Dye-based
Number of Ink Colors	6
Connectivity	USB, Wi-Fi, Ethernet
Functions	Print, Copy, Scan
Memory Card Compatibility	SD, SDHC, SDXC
Ink Tank System	Yes
Paper Sizes Supported	A4, A5, A6, B5, Letter, Legal, 10 x 15 cm, 13 x 18 cm, 16:9
Duplex Printing	Yes
Scanner Type	Flatbed
Display	4.3-inch Color LCD
Printing Speed ISO/IEC 24734	16 ppm (black), 12 ppm (color)
Scanning Resolution	1200 x 4800 dpi
Print Speed (Black)	16 ppm
Print Speed (Color)	12 ppm
Ink Cartridge Configuration	6 individual ink tanks
Paper Capacity	100 sheets
